Barcode

Barcode Scaner

ST-760L Laser Barcode Scanner

  • Scan Speed: 100times/s
  • Optical Source: 650nm Visible red light diode
  • Image Resolution: >4mil
  • Minimum Contrast: >30%
  • Indicator: Siren and LED light
  • Working Voltage: DC5V
  • Height Range: 1.5m
  • Interface Type: USB, serial or KBW

ST-1010 Laser Barcode Scanner

  • Light source: visible laser diode, 650Nm
  • Scan rate: 300 scans per second
  • Scanning angle: ±60° ±65° ±42° (left and right, front and back, turn)
  • Scanning width: 30mm at scanning window 220 at 200mm
  • Scanning type: single-line
  • Resolution: 0.1mm (4 mil) at pieces 0.9
  • Depth of scanning field: 0-250mm (0.33mm, pieces 90%)
  • Indicator light: LED diode

ST-1020 Linear Barcode Scanner

  • Light Source: 660nm red visible LED
  • Decoded Capability: All 1D Barcodes
  • Scanning Principle: Image linear CCD
  • Scanning Method: Manually / Successive Scanning (Optional)
  • Scanning Speed: >270 scans per second
  • Scanning Angle: Yaw 55°, Rotation 30°, Pitch 65°
  • Scanning Precision: 4mil(0.1mm)
  • Depth of Scanning Field: 5-390mm
  • Error Rate: < 1/5million
  • Communication Interface: USB-HID, Rs232

ST-760A Auto Sense Laser Barcode Scanner

  • Trigger Mode: Manul and auto-induction
  • Scan Speed: 100times/s
  • Optical Source: 650nm Visible red light diode
  • Image Resolution: >4mil
  • Minimum Contrast: >30%
  • Indicator: Siren and LED light
  • Working Voltage: DC5V
  • Height Range: 1.5m

ST-1000 CCD Barcode Scanner

  • Optical Source: 620nm Visible red light diode
  • Imaging Sensor: CCD
  • Resolution Ratio: 2500 pixel
  • Image Resolution: >5mil
  • Minimum Contrast: >30%
  • Decoding Speed: 280times/second
  • Indicator: Siren and LED light
  • Interface Type: USB, Serial or KBW

ST-2010 2D Barcode Scanner

  • White and red light source, wide angle camera, allowing maximum light collection and no disturbance by reflection.
  • Leading visual chromatographic technology ensure high initial recognition rate.
  • IP 54 Industrial grade, dual Water resistance on trigger, interface and buzzer
  • Reads all normal 1D and 2D barcodes.
  • Reads barcodes on PC and Mobile Phone displays.
  • Extra rugged design: withstand to 1.8m drop to concrete, corrosion resistance and case can be sterilized.

ST-1010W Wireless Laser Barcode Scanner

  • Lowest Price
  • 2.4G Wireless Laser Barcode Scanner
  • 300 Scans/Sec Speed
  • Supports 4mil barcodes
  • Up to 10 meters Wireless Distance
  • with Memory
  • Up to 250mm Depth of Field
  • Reads all 1D Barcodes

ST-904 Wireless Laser Barcode Scanner

  • Scan Element Type: laser
  • Optical Source: 650nm Visible red light diode
  • Trigger Mode: Manul
  • Colour Depth: 24 Bit
  • Depth Filed: 5mm-630mm
  • Reading Percision: >4mil
  • Decoding Speed: 100times/s
  • Bit error rate: 1/50million
  • Indicator: Siren and LED light
  • Data Interface : RJ-45
  • Working Voltage: DC5V
  • Max.Power: 520mw
  • Height range:1.5m
  • IP Rating: IP52
  • Wireless Distance : 30 to 400mtrs

ST-1503 Wireless CCD Barcode Scanner

  • Wireless Transmitting Distanc: 30 - 400m
  • Optical Source: 620nm Visible red light diode
  • Imaging Sensor: CCD Resolution
  • Ratio: 2500 pixel
  • Image Resolution: >5mil
  • Minimum Contrast: >30%
  • Decoding Speed: 280times/second
  • Indicator: Siren and LED light

ST-2020 2D Bluetooth Barcode Scanner

  • Light source: 2D Aimer: 617nm LED white 6500K, illumination: 625nm LEDs
  • Scan rate: >25-inch/63per each second
  • Scanning width: 5-390mm
  • Scanning type: CMOS
  • Resolution: SR, code 39 4. 8mil, UPC 60% 5mil, PDF417 5mil, datamatrix 7. 5mil
  • Indicator light: white
  • Interface support: USB, PS2 and RS232
  • Charge interface: micro USB, red lighting is in charging, red light off battery full charge
  • Charge: ≥3 hours
  • Battery working: 9 hours per full charge

ST-1000 1D Omni Barcode Scanner

  • Scan Pattern : 5 field of 4 parallel lines
  • Scan Speed : 2100 scan lines per second
  • Print Contrast : 30% minimum reflectance difference
  • 150 Scan/Sec speed for Laser
  • Scanning Angle : Horizontal: 72° Vertical: 82°
  • Decode Capability : All 1D Barcodes
  • Light Source : Wavelength: 650±8nm red laser
  • Host System Interface : USB2.0, PS/2,RS232, USB Virtual RS232
  • LED Indicator : Buzzer and bi-color light( Red-power, Blue-decoding Successfully)

ST-2000 2D Omni Barcode Scanner

  • Anti-reflective technical Exclusively: All kinds of barcode covered by glossy or special surface can be decoding quickly. such as infusion bags, plastic medicine packaging. Applicable to retail, manufacturing, medical, logistics and other industries.
  • Dual focus optical control technology Exclusively: High density and wide barcode available;
  • Good Screen capture ability: Payment barcode, Electronic Coupon on mobile devices can be decoding easily;
  • High speed camera optical technology and high-speed core architecture, Clocked at 1.2G, Design for the retail industry high speed scanning bar code.
  • Decoding Ability: All 1D and 2D Barcodes
  • Speed: 2100 times/sec
  • Light Source: High Brightness, Infrared LED

ST-2000 Omni Directional Barcode Scanner

  • Depth of Field:0-220mm
  • 20 Scan lines in 5 directions
  • 1500times/second on Omni-directional scan mode
  • Minimum resolution: 5mil( can be adjusted to 4mil)
  • Supports both Omni-directional and single-line scan
  • Minimum Resolution: 5mil@PCS90%
  • Depth of Field : 0-200mm for 0.33mm UPC/EAN 100%

ST-1030P /1040P Barcode Scanner

  • Micro USB Smartphone Barcode Scanne
  • PDA Replacement partly
  • Wire to be Wireless
  • 150 Scan/Sec speed for Laser
  • Data Real Time Upload
  • 150 Scan/Sec speed for Laser
  • Data Real Time Upload
  • 350 Scans/Sec speed for Linear
  • No need Bluetooth

ST-1401 BT Barcode Scanner for Andriod, Windows & IOS

  • Scan Element Type: CCD
  • Height Range: 1.5m
  • BT support : Android, IOS, MAC, PDA Etc.,
  • IP Rating: IP52
  • Optical Source: 620nm Visible red light diode
  • Colour Depth: 32 Bit
  • Optical Resolution: 2500
  • Interface Type: USB
  • Wireless Transmitting Distanc: 15 - 20m
